MikroTik CRS305-1G-4S+IN

The CRS305 is a small but powerful switch with four SFP+ ports capable of up to 10 Gbit per port. The gadget contains two DC connectors for power redundancy and a 1 Gbit copper ethernet port for management access. The device has a sleek and tiny metallic case with no fans, allowing for silent operation.

The device offers a "Dual boot" capability that allows you to select between RouterOS and SwOS. SwOS is a streamlined operating system that solely includes switch-specific capabilities. Use RouterOS if you want to use routing and other Layer 3 technologies in your CRS. You can choose an operating system from RouterOS, SwOS, or the RouterBOOT loader settings. The entire feature set is available at a competitive price, delivering the best price/performance ratio on the market.

MikroTik CRS305-1G-4S+IN

Specifications

Details
Product code CRS305-1G-4S+IN
Architecture ARM 32bit
CPU 98DX3236
CPU core count 1
CPU nominal frequency 800 MHz
Dimensions 141 x 115 x 28 mm
License level 5
Operating System RouterOS / SwitchOS
Size of RAM 512 MB
Storage size 16 MB
Storage type FLASH
Tested ambient temperature -40°C to 70°C
Suggested price

Powering

Details
PoE in 802.3af/at
PoE in input Voltage 12-57 V
Number of DC inputs 3 (PoE-IN, DC jack)
DC jack input Voltage 12-57 V
Max power consumption 18 W
Max power consumption without attachments 10 W

Ethernet

Details
10/100/1000 Ethernet ports 1

Fiber

Details
SFP+ ports 4

Other

Details
CPU temperature monitor Yes
